RAmi Audio AMC120

The RAmi Audio AMC120 is a standalone headphone amplifier with red and green LED indicators for studio and microphone status, a volume control and switched talkback. The AMC120 is designed to be recessed into studio furniture and is powered from an external 12 to 24 volt dc supply. There is the ability to limit the headphone output level using dip switches to comply with health and safety standards. Units can be daisy chained together for individual positions around the studio.

  • One headphone output with a volume on front panel.
  • Two 1/4" headphone connectors.
  • One "ON-Air" light.
  • One signal input, using female Sub-D 15.
